Product overview
The GBOX 445nm blue laser represents an innovative extension to the already established surgery laser systems. “CO2 + KTP”-like laser unit for coagulation, vaporisation and bloodless surgery thanks to its peak absorption in hemoglobin and its permeability in water. The blue laser light interacts better with the tissue components hemoglobin or melanin. At 445 nm, this enables considerably better and gentler cutting, even at lower power. Improved cutting performance make it ideally suited to all surgical applications and for hemostasis.

Advantage

• Compact design: small size and light weight, easy to transport.
• Green aiming beam improves alignment and exact sighting during treatment.
• “CO2 + KTP”-like laser unit for coagulation, vaporisation and bloodless surgery.
• Both contact and non-contact mode cutting with simultaneous coagulation.
• Fiber guide laser compatible with various endoscopic use.

Application
SURGERY / GYNECOLOGY

• Treatment of early Laryngeal Carcinoma
• Dysplasia Removals
• Endoscopy / Micro endoscopy
• Fibroma and Granuloma Resection
• Glottic Carcinoma Resection
• Haemangioma and Ectasia Coagulation
• Haemangioma
• Congenital Larynx Stenosis
• Larynx / Oropharynx
• Laser-assisted Uvulopalatoplasty
• Microsurgery of the Vocal Fold
• Neoplastic Stenosis
• Otology
• Papillomatosis
• Partial Glossectomy
• Polypectomy in the Vocal Cord area
• Reinke-Oedema
• Rhinology
• Vocal Cord Nodules
• Vocal Cord Lesions
• Telangiectasia
• Tonsillotomy
• Tracheal Stenosis
• Tumour Excision
• Vascular Lesions
• Zenker’s Diverticulum
• Cysts, Mucoceles
• Cyst Removal

ENT

• Treatment of early Laryngeal Carcinoma
• Dysplasia Removals
• Endoscopy / Micro endoscopy
• Fibroma and Granuloma Resection
• Glottic Carcinoma Resection
• Haemangioma and Ectasia Coagulation
• Haemangioma
• Congenital Larynx Stenosis
• Larynx / Oropharynx procedures
• Laser-assisted Uvulopalatoplasty
• Microsurgery of the Vocal Fold
• Neoplastic Stenosis treatment
• Otology procedures
• Papillomatosis treatment
• Partial Glossectomy
• Polypectomy in the Vocal Cord area
• Reinke-Oedema management
• Rhinology applications
• Vocal Cord Nodules and Lesions
• Telangiectasia treatment
• Tonsillotomy
• Tracheal Stenosis
• Tumour Excision
• Vascular Lesions
• Zenker’s Diverticulum
• Cysts and Mucoceles removal

VETERINARY MEDICINE

• General Veterinary Medicine applications

Desktop optional
Desktop version/option available as shown on the product page (brochure available separately).

Technical Specifications (table values)
Model: GBOX™ Blue
Wavelength (page header/body): 445 nm
Wavelength (technical table): 455 nm
Maximum Power: 10W / 30W
Operation Mode: CW, Single Or Repeat Pulse
Pulse Duration: 500μs-10s
Repetition Rate: 0.05Hz-1KHz
Transmission System: Fibers of 400um and 600um with SMA905 connector
Pilot Beam: Red diode laser of 635nm, Power <5mW
Control Mode: True color touch screen
Voltage/Current Rating: 110/220 VAC, 5A, 50/60 Hz
Dimensions: 215(W) * 245(L) * 315(H) mm
Weight: 4 Kg
Specifications subject to change without notice.

Caractéristiques / Spécifications techniques

• Model: GBOX™ Blue
• Advertised wavelength in descriptive text: 445 nm
• Wavelength (technical table): 455 nm
• Maximum Power: 10W / 30W
• Operation Mode: CW, Single Or Repeat Pulse
• Pulse Duration: 500 μs – 10 s
• Repetition Rate: 0.05 Hz – 1 kHz
• Transmission System: Fibers of 400 μm and 600 μm with SMA905 connector
• Pilot Beam: Red diode laser 635 nm, power < 5 mW
• Control Mode: True color touch screen
• Voltage/Current Rating: 110/220 VAC, 5 A, 50/60 Hz
• Dimensions: 215 × 245 × 315 mm (W×L×H)
• Weight: 4 kg
