Laser für vaskuläre Läsionen LASEVIA

für Vulvo-Vaginalplastikfür Lipolysefür physikalische Biostimulation

Présentation
LASEVIA is a multi-wavelength semiconductor (diode) laser platform uniting 1940 / 1470 / 980 / 635 / 450 nm sources in one portable console. Peak output up to 30 W+ across configuration-dependent wavelengths; Class 4 medical laser with an 11.6-inch Android smart touchscreen and safety hardware for clinic use.

Wavelength architecture

• Factory configurations: Configuration A = 1940 · 1470 · 980 · 635 nm; Configuration B = 1470 · 980 · 450 · 635 nm.
• Each diode is matched to chromophores: water, haemoglobin, lipid or melanin; wavelengths independently switchable and combinable.

Clinical applications (Eight specialties)

• Endolifting — deep 1940 nm fractional fiber remodels superficial and deep layers for non-surgical lifting (face, neck, body).
• Lipolysis — 1470 / 980 nm ring-light fiber emulsifies adipose via micro-cannulas for mini-invasive body contouring.
• Spider Vein & Vascular — transdermal and endovenous coagulation (980 / 1470 nm) plus 635 nm surface mode.
• Therapy · HILT Class IV — deep-tissue photobiomodulation for pain, inflammation and tissue repair (980 / other therapeutic wavelengths).
• LVR (Laser Vaginal Rejuvenation) — non-ablative 635 nm intimate-health protocol.
• Proctology — fiber-delivered coagulation for haemorrhoids and fistulae (980 / 1470 nm).
• EVLT — endovenous laser ablation using 1470 / 1940 nm for vein sealing.
• ENT — 450 nm blue diode for minimally invasive ear, nose and throat soft-tissue surgery.

Delivery, handpieces & accessories

• Universal SMA905 fiber interface accepts contact fibers 200 / 400 / 600 / 1000 µm and non-contact tips.
• Handpiece sets: Basic (endolifting · lipolysis), Advanced Liposuction, SUPERSCAN Focus (spider vein · fractional), LVR, PM5 therapy, disposable LVR and disposable surgical sets.
• Fiber types: High-power fiber, Bare fiber (direct contact), Polyimide-coated fiber, Radial fiber, Hemorrhoid fiber (typ. 600 µm).
• Accessories: laser safety goggles, foot switch, fiber cutter, fiber stripper, connector cleaner.

Device & interface features

• 11.6" Android smart touchscreen with touch presets, real-time energy readouts and one-tap protocol recall.
• Portable console ~15 kg with single-handle carry frame; desktop footprint with operating-room safety hardware.
• Emergency laser stop (mushroom switch) and mechanical safety shutter.
• Four professionally tuned UI themes included (Lavender White, Fantasy Purple, Obsidian Purple, Mist Blue).

Emission modes & performance

• Emission modes: Continuous Wave (CW), single pulse, repeat pulse.
• Pulse width: 25 µs – 10 s.
• Repetition rate: 0.05 Hz – 50 kHz.
• Maximum output: up to 30 W+ (configuration-dependent).

Caractéristiques / spécifications techniques

• Laser type: Multi-wavelength semiconductor (diode) laser platform.
• Wavelengths: 450 / 635 / 980 / 1470 / 1940 nm — configuration dependent.
• Maximum output: Up to 30 W+ (configuration-dependent).
• Configuration A: 1940 nm 10 W · 1470 nm 15 W · 980 nm 20 W · 635 nm 500 mW · fiber 200 µm.
• Configuration B: 1470 nm 15 W · 980 nm 30 W · 450 nm 8 W · 635 nm 2 W · fiber 200 / 400 µm.
• Emission modes: CW · single pulse · repeat pulse.
• Pulse width: 25 µs – 10 s.
• Repetition rate: 0.05 Hz – 50 kHz.
• Delivery system: SMA905 fiber interface; contact fibers 200 / 400 / 600 / 1000 µm; non-contact tips.
• Interface: 11.6" Android smart touchscreen.
• Safety: Emergency laser stop · mechanical safety shutter · Class 4.
• Power supply: 100 – 240 V, 50 – 60 Hz, 350 VA.
• Weight: 15 kg (portable console).
• Certification / Quality: CE · MDSAP · ISO 13485 · FDA‑cleared therapeutic laser lineage.
